Grass 110 Degree Hinge for Back-to-Back Overlay Cabinets (48 mm Screw Hole Spacing) – Bundle

• Half cranked hinge bundle for back-to-back frameless cabinets with overlay doors.
• Can also be used for frameless cabinets with a smaller overlay than a typical straight arm type hinge (also known as half overlay).
• These hinges can be used to replace old Mepla brand hinges which have a 48mm screw hole center to center spacing.
• You will no longer find new hinges with “Mepla” stamped on them, as Mepla and Grass merged in 2007 to simply become Grass.
• Please see the “Reveal & Overlay Information” document below to verify if this bundle will work for your application.

Features

• Four different adjustments:
  • Depth adjustment ( 3mm and -1mm)
  • Side adjustment / Overlay ( 1mm and -3mm)
  • Height adjustment ( 2mm and -2mm)
  • See the document found under Downloads for information on how to adjust

Details

• Hinge cup size is 35mm (1-3/8″). Cup depth is 11mm (7/16″).
• Door opening angle is 110 degrees
• Works for bore distances from 3mm (1/8″) to 7mm (9/32″)
• Works for overlay dimensions from 1mm (1/32″) to 13mm (1/2″)
• Works for door thicknesses from 16mm (5/8″) to 22mm (7/8″)

What’s Included

• 1 x Grass “Nexis 110” Half Cranked Hinge with 48mm center to center spacing
• 1 x 2mm Frameless Mounting Plate
• 4 x #6 x 5/8″ Flat Head Wood Screws for the Hinge and Mounting Plate

Optional Accessories – Available for purchase separately:

• Soft-Close Add-On Device – Eliminates slamming of the door and dampens the closing action.
• Plastic Dowels and Dowel Screws, used on manufactured wood products where wood screws do not hold well (SKUs 652368 and 701115)
• 35mm Forstner Bit, for new installations (SKU 204000)
