Adams Rite 1000-21-32-130 Turn with Escutcheon and Pendicular Drive with 1-55/64" Spindle Aluminum Finish

• Materials: Turn Lever: Zinc alloy, trim finish 130; Escutcheon: Stainless steel, trim finish 130.
• Spindles: Hardened steel, plated for corrosion resistance. First dash number in order guide indicates spindle parallel or perpendicular to turn level. Second dash number indicates spindle length “L”. See dash table on catalog page.
• 1004 Turn: 1004 Turn has a longer, more ergonomically-friendly turn lever.
• 1015 Turn: Available with 1016 blank plate for doors from 5/8 to 2-1/4thickness. Without blank plate turn available (for use with cylinder pull) on doors from 7/16 to 2 thickness. Standard finish 130, Satin Aluminum enamel. Turn 1015 for use with 5017 lock is designed for wood door applications.
• Standard Package: Individually packaged. Dash-21 and Dash-11 assembled, with escutcheon. Dash-01 and -02, unassembled, include turn, spindle, washer and push nut for assembly on the door pull plate. Shipping weight: 1/16 lb.

Color

Satin Aluminum Ritecoat Paint

Color Code

628

Package Qty

1

Finish

Satin Aluminum

Function

Thumbturn

Finish Description

Satin Aluminum

Finish Family

Aluminum

Product Type

Lock Part/Accessory

Series

Parts/Accessories

Manufacturer Parent

Assa Abloy

Screw Type

Flat Head Screw

For Use With

Adams Rite MS 1847 Deadlocks and 5017 Wood Door Deadlock

Product Width

5/8 Inch

Sub-Series

1000-21-32-130

Handle Type

Turn Lever

Product Height

1-13/16 Inch

Product Projection

7/16 Inch

Features

Pendicular Drive; 1000-21 Have a Rectangular Escutcheon for Mounting Directly on Door

Product Material

Zinc Alloy (Turn Lever); Stainless Steel (Escutcheon); Hardened Steel (Spindle)

Hole Center to Center

1-5/16 Inch

Escutcheon Thickness

5/32 Inch

Screw Size

#6

Lever Size

1-1/4 Inch

Escutcheon Size

1-13/16″ x 5/8″

Product Overview

Turn Trim and Escutcheon, MS1847, Pendicular Drive, 1-55/64″ Spindle, Aluminum

Designed to operate Adams Rite MS1847 Deadlocks and the 5017 Wood Door Deadlock.

Options: The availability of both perpendicular and parallel drives in these turns, coupled with the three hub drive positions of the MS1847 lock, provides several options. Choice of turn drive position relates directly to the particular lock hub drive position. Special care in specifying both the proper turn and lock in ordering is recommended. Chart in catalog shows turn positions relative to lock hub positions. Broken line indicates direction of travel (45) to retract bolt (see chart on catalog page).
